QUALITY IN LARGE-FORMAT
With a robust frame and components, plus an actively heated build chamber, VIIO 250 delivers industrial quality in large scale.
250 LITERS BUILD CHAMBERHEATED UP TO 50°C
DUAL SMX EXTRUDERS FORPRECISION AND SPEED
LARGE & COMPLEX PRINTS
Dual SMX extruders tackle complex geometries, while continuous printing features can process up to 32 kg with hands-off production.
PRINT ENGINEERINGMATERIALS UP TO 350°C
ENGINEERING MATERIALS
Thanks to precisely controlled SMX extruders, VIIO 250 reaches up to 350°C for complex prints with engineering-grade materials.
BigRep Viio 250 - STREAMLINED AUTOMATION FOR ALL INDUSTRIES
AUTOMOTIVE-GRADE COMPONENTS
Manufacture robust parts tailored for automotive applications. The VIIO 250 uses engineering-grade materials to create sturdy, lightweight components. High precision and resolution support innovation across the design process.
FUNCTIONAL PROTOTYPING
Validate designs and test prototypes before final production. Benefit from an open-material system offering flexibility with various filaments to replicate final parts accurately. Speed up iterations, cut down production costs, and accelerate time-to-market.
DURABLE TOOLING
Produce cost-effective rapid tooling like jigs and fixtures directly on your factory floor. Leveraging automation features, create intricate tooling in-house, surpassing traditional methods and enabling on-demand production.
Features
EXPANSIVE HIGH-RESOLUTION PARTSLarge Build Volume
Achieve precise geometric accuracy with the VIIO 250's actively temperature-controlled build chamber measuring 1000 mm x 500 mm x 500 mm (250-liter volume), heating up to 50°C. Its compact, robust design enables large-format printing in any workspace. Automatic portal leveling ensures consistent print quality, even after relocating the machine.
OPTIMIZED PRODUCTIVITY24/7 Automated Operations
Experience desktop printer comfort at an industrial scale with automated bed mapping, filament flow adjustment, and x/y calibration. The VIIO 250 features advanced automation tools: the Infinity Box and Relay Mode.
The Infinity Box automatically loads new filament mid-print, ensuring uninterrupted operation. Meanwhile, Relay Mode provides backup extruder functionality for reliable performance. Enjoy industrial CNC quality with instant over-the-air software updates for continuous enhancement.
PRECISION PRINT MANAGEMENTDual Smart Manufacturing Extruders (SMX)
Equipped with dual SMX extruders capable of printing up to 350°C, the VIIO 250 handles engineering-grade and carbon-fiber materials effortlessly. LED indicators on the extruders provide at-a-glance status updates, while embedded sensors and nozzle options (0.4mm, 0.6mm, and 1.0mm) ensure consistent high-resolution prints.
USER-FRIENDLY INTERFACE & WORKFLOWIntuitive Machine Operation
Navigate the VIIO 250 with ease using its multi-lingual interface and animated guides. Clear information, alerts, and warnings streamline print management. The Print Queue feature optimizes workflow by prioritizing and scheduling print jobs for maximum efficiency.
SEAMLESS FILAMENT MANAGEMENTThe Infinity Box
Automatically handle filament changes with the Infinity Box, which detects and replaces empty spools during active prints. It also serves as a keep-dry container, accommodating up to 4 spools (8kg each) in optimal storage conditions.
RELIABLE PRINT BED ADHESIONVersatile Material Compatibility
Maintain consistent part adhesion with a heated print bed reaching 120°C and SWITCHPLATE® surface. The flexible magnetic bed supports various coatings for different materials, ensuring easy part removal after cooling.
These enhancements make the VIIO 250 ideal for diverse industrial applications, from automotive-grade parts to functional prototypes and rapid tooling
BigRep VIIO 250
Technical Specifications
Technical Specifications
|
Version
|
BigRep VIIO 250
|
|
Build Volume
|
1000mm x 500mm x 500mm (x,y,z)
|
|
Compatible materials
|
BigRep ASA, BVOH, HI-TEMP, HI-TEMP CF, PA12 CF, PA6/66, PETG, PLA, PLX, PRO HT, TPU 98A (Open for 3rd party materials)
|
|
Support materials
|
BigRep BVOH (Open for 3rd party materials)
|
|
Extruders
|
Dual Smart Manufacturing Extruders (SMX)
|
|
Nozzles
|
Tungsten carbide (0.4mm, 0.6mm) or polycrystalline diamond (1.0mm)
|
|
Nozzle diameters
|
0.4mm, 0.6mm, 1.0mm
|
|
Layer thickness
|
0.2mm, 0.3mm, 0.5mm (Other layer heights supported through slicer software)
|
|
Extruder temp
|
Up to 350°C
|
|
Build chamber temp
|
30-50°C
|
|
Print bed temp
|
Up to 120°C
|
|
Removable print surface
|
SWITCHPLATE prime, SWITCHPLATE select
|
|
Max print speed
|
Up to 500 mm/s
|
|
Max throughput
|
Up to 166cm³/h
|
|
Position accuracy
|
±0.004mm in XY, ±0.003mm in Z
|
|
Drive technology
|
Stepper motors with steel reinforced belt drive in XY, Spindle with self-lubricating nut in Z
|
|
Connectivity
|
10/100/1000 Base T Connection Ethernet Protocol, USB Port, BigRep Connect Ready with remote monitoring/control features
|
|
Slicing software
|
BigRep BLADE
|
|
Machine control
|
BigRep Kreuzboard
|
|
HMI
|
12.1” touchscreen
|
|
Camera
|
Built-in chamber camera for real time remote monitoring
|
|
Power supply
|
208-240 V, 50/60Hz, 16 A
|
|
Power consumption
|
Average (while printing): 660W, Peak: 3200W
|
|
External dimensions
|
1634mm x 1069mm x 1829mm (x,y,z)
|
|
Weight
|
560kg printer in base configuration, 62kg Infinity Box
|
