0.02mm
Accuracy
0.02mm
Resolution
120 FPS
Scanning Speed
Stunningly accurate models – every time
With super high accuracy, solid tracking, and dedicated modes for complex geometries, the Artec Point 3D scanner captures high-resolution metrology data you can count on.
Technical Specifications
View All Specs >
Scanner Type — Handheld
3D Light Source — Blue Laser, Class II (Eye-Safe)
3D Point Accuracy — 0.02mm (0.0008 in)
Volumetric Accuracy, up to — 0.015 mm + 0.035 mm/m (0.0006 in + 0.0014 in/ft)
0.015 mm + 0.015 mm/m with Artec Metrology Kit (0.0006 in + 0.0006 in/ft)
Weight — 570 grams (20.1 oz)
Scanning rate, up to — 2.8 million measurements/s
Capture rate, up to — 120 FPS
Scanning Area — 700 x 600mm (27.6 x 23.6in)
Depth of field — 550 mm (21.7 in)
Size of Scanning object / area — S-L
Certification — ISO 17025 accredited based on VDI/VDE 2634 & JJF 1951
