Introducing the Nimbletrack Gen2
Track Further, Scan Bigger
Equipped with edge calibration algorithms and a robust CFFIM structure, NimbleTrack Gen2 offers a tracking distance of up to 4.2 meters, making it ideal for small to mid-sized objects while maintaining precision for large and extra-large parts.
Accuracy You Can Trust
Accuracy You Can Trust
Powered by our metrology-grade hardware and in-house developed algorithms, this mode delivers up to 0.025-mm system accuracy and 0.059-mm volumetric accuracy—marker-free and ideal for dynamic scanning of small to mid-sized parts.
Lightning-fast Scanning
Next-generation edge computing in both the scanner and tracker enables smooth, high-speed scanning at 120 FPS. In high-speed mode, NimbleTrack Gen2 achieves a scan rate of 6.63 million measurements per second using 27 blue laser crosses. Even complex surfaces and fine details are captured rapidly and accurately, boosting productivity in industrial inspection.
Technical Specifications
NimbleTrack Gen2
Wireless Optical 3D Scanning System
Further, Faster, Mightier
Scanner Specifications (i-Scanner)
| Dimensions | 252 mm × 195 mm × 260 mm |
| Weight (Net) | 1.3 kg |
| Weight (with Battery & Wireless) | 1.4 kg |
| Scanning Area | 500 mm × 600 mm |
| Stand-off Distance | 300 mm |
| Depth of Field | 400 mm |
| Resolution | Up to 0.020 mm |
| Scanner-only Mode Accuracy | 0.060 mm (C) / 0.059 mm (E) |
Tracker Specifications (i-Tracker)
| Dimensions | 570 mm × 87 mm × 94 mm |
| Weight (Net) | 2.2 kg |
| Weight (with Battery & Wireless) | 2.6 kg |
| Tracking Distance | 3.5 m (C) / 4.2 m (E) |
| System Accuracy | 0.072 mm + 0.012 mm/m (C) 0.044 mm + 0.012 mm/m (E) |
| Volumetric Accuracy | Up to 0.025 mm |
| Hole Position Accuracy | 0.050 mm |
Performance Specifications
| Scanning Frame Rate | 120 fps |
| Measurement Rate | Up to 6,630,000 measurements/s |
| Ultra-fast Scanning | 54 blue laser lines |
| Hyperfine Scanning | 17 blue parallel laser lines |
| Large Area Scanning | 54 blue laser lines |
| Deep Hole Scanning | 1 extra blue laser line |
| Laser Class | Class II (eye-safe) |
Technical Specifications
| Operating Temperature | -10°C to 40°C |
| Operating Humidity | 10-90% RH (Non-condensation) |
| Wireless Standard | Wi-Fi 6, 802.11a/b/g/n/ac |
| Interface Modes | USB3-B, Gigabit Ethernet port |
| Protection Case Size | 1000 mm × 425 mm × 280 mm |
| Output Formats | .stl, .obj, .ply, .asc, .igs, .txt, .mk2, .umk and more |
Key Features & Operating Modes
Fully Wireless
Complete wireless freedom with high-performance batteries and advanced edge computing
Dual-Mode System
Combines optical 3D scanning with handheld wide-area scanning flexibility
Adaptive Photogrammetry
Ensures exceptional accuracy for both long and short measurement distances
Edge Inspection
Precise inspection of closed features like holes, slots, and edges with gray-value measurement
Custom Adapters
6D pose tracking of target objects in real-time for dynamic applications
Tracking i-Probe
Contact measurement probe for inaccessible areas with wired and wireless options
Multi-Tracker Tracking
Wireless multi-tracker support for enhanced coverage and accuracy
Non-Target Scanning
Marker-free scanning ideal for dynamic measurement of various part sizes
