Revolutionize How You Print Your Projects
Painting intricate models is a thing of the past — the H2C brings your designs to life with six-color printing and a versatile seventh nozzle for support or an additional color. This whole thing is printed in 2 parts. The main raptor is 6-color and the base is another 6-color.
Purge Saving Multi-Color Printing
Painting intricate models is a thing of the past — the H2C brings your designs to life with six-color printing and a versatile seventh nozzle for support or an additional color. This whole thing is printed in 2 parts. The main raptor is 6-color and the base is another 6-color.
Purge and Prime Tower Waste
532g H2C
3032g H2D
3917g H2S
Bring Your Ideas to Life in Full Color with Minimal Waste.
A race car with racing stripes? Yes, you can print it straight out! Forget the hassle of painting or wasting tons of filament.
7 Colors. One Print. No Paint.
An anime-style fighter plane in full color — no paintbrushes, no glue, no fuss.Simply load your filaments and print a flawless one-piece model in no time.
Print Durable Joints — Built Right Into the Parts.
Integrated TPU Joints for Multi-Color Parts
Print durable TPU ball joints for your robot models — flexible, long-lasting, and built for endless motion.
No More Assembly — Print Multi-Material Parts in One Piece.
Purge Saving Multi-Material Printing
With the H2C, you can print up to seven different materials in a single run — no nozzle purging required. Combine multiple material properties in one seamless structure and take integrated design to a whole new level.
Why Vortek?
Small Form Factor, More Filaments
Small Form Factor, More Filaments
Because only the hotend is swapped, the system can house up to six replaceable hotends without significantly reducing the build volume.That means more materials, more colors, and more possibilities — all in one print.
8-Second Induction Heating
Our industry-leading induction heating technology brings the nozzle to temperature in 8-sec, significantly reducing the preheating time for each material swap compared to traditional methods.
Colors Are No Longer Limited By How Many Toolheads You Have
Unlike traditional toolchanger printers that limit color count by the number of toolheads, the H2C supports up to 24 materials in a single print through parallel-connected AMS units. Its intelligent algorithm optimizes filament-to-hotend allocation to minimize purge waste while delivering outstanding multi-color and multi-material results.
Unlike traditional toolchanger printers that limit color count by the number of toolheads, the H2C supports up to 24 materials in a single print through parallel-connected AMS units. Its intelligent algorithm optimizes filament-to-hotend allocation to minimize purge waste while delivering outstanding multi-color and multi-material results.
Enclosed for High-Performance Printing
With its seamless enclosure and adaptive airflow system, the H2C maintains a stable chamber temperature for high-performance materials and filters the air to keep your workspace clean and safe.
Fully Automatic Nozzle Offset Calibration
Our inductive nozzle offset calibration is fully automated — no manual steps, no calibration plates, no extra setup. In just a few minutes, the H2C precisely calibrates nozzle offset to within 25 microns.*
Our inductive nozzle offset calibration is fully automated — no manual steps, no calibration plates, no extra setup. In just a few minutes, the H2C precisely calibrates nozzle offset to within 25 microns.*
Dedicated Hotends for Specific Filaments
The H2C's Vortek system lets you dedicate one of its six interchangeable hotends to specific filaments — a game-changer for valuable engineering materials.This ensures superior consistency and reliability across prints. Each hotend can even automatically store filament information, so the next time you load that material, it's instantly matched to the correct hotend.
70% More Extrusion Force & Real-Time Error Detection.
The PMSM servo extruder delivers up to 10 kg of maximum extrusion force—70% more than stepper motor—dramatically improves high-flowrate extrusion stability. Our proprietary servo architecture samples resistance and position at 20 kHz, actively detecting filament grinding and clogs in real time.
The PMSM servo extruder delivers up to 10 kg of maximum extrusion force—70% more than stepper motor—dramatically improves high-flowrate extrusion stability. Our proprietary servo architecture samples resistance and position at 20 kHz, actively detecting filament grinding and clogs in real time.
Bambu Lab H2C - Technical Specifications
Printing Technology
Fused Deposition Modeling
Body
Shell Volume (W*D*H)
Single Nozzle Printing: 520*520*720 mm² (±5%)
Dual Nozzle Printing: 520*520*690 mm² (±5%) (Right)
Dual Nozzle Printing: 520*520*540 mm² (±5%) (Left)
Total Volume for Tool Changer: 520*520*720 mm² (±5%)
Dual Nozzle Printing: 520*520*690 mm² (±5%) (Right)
Dual Nozzle Printing: 520*520*540 mm² (±5%) (Left)
Total Volume for Tool Changer: 520*520*720 mm² (±5%)
Chassis
Aluminum and Steel
Net Weight
~55 kg
Physical Dimensions
Physical Dimensions
650*670*930 mm²
Net Weight
55.5 kg
Toolhead
Extruder Case
Hardened Steel
Nozzle
Stainless Steel
Max Nozzle Temperature
350°C
Compatible Nozzle Diameter
1.75mm
0.4 mm, 0.6 mm, 0.8 mm, 1.0 mm
0.4 mm, 0.6 mm, 0.8 mm, 1.0 mm
Filament Cutter
Built-in
Filament Diameter
1.75mm
Extruder Motor
Samdco ultra High-precision Permanent Magnet
Synchronous Motor
Heatbed
Build Plate Material
Flexible Steel Plate
Included Build Plate Type
Cool Plate
Supported Build Plate Type
Textured PEI plate, Engineering Plate
Max Heatbed Temperature
120°C
Speed
Max Speed of Toolhead
1000 mm/s
Max Acceleration of Toolhead
30,000 mm/s²
Max Flow for Heatend
40 mm³/s (3-hour parameter), 300-mm curved-extrusion with a 0.4mm nozzle
35 mm³/s (5+ hour with 5+ kg printing)
35 mm³/s (5+ hour with 5+ kg printing)
Chamber Temperature Control
Active Chamber Heating
Supported
Max Temperature
65°C
Air Purification
Fine Filter Grade
G3
Home Filter Grade
H12
Activated Carbon Filter Type
Activated Coconut Shell
HEPA Filtration
Supports
Particulate Matter Filtration
Supported
Cooling
Part Cooling Fan
Closed-Loop Cooling
Cooling Fan for Hotend
Supported
Main Control Board Fan
Closed-Loop Cooling
Chamber Exhaust Fan
Supported
Chamber Heat Dissipation Fan
Closed-Loop Cooling
Toolhead Cooling Fan
Supported
Southeast Enhanced Cooling Fan
Closed-Loop Cooling
Supported Filament Type
PA, PA-CF, PA-GF, BVOH, HIPS, ePA-CF (ePA-CF+GF), Carbon/Glass Fiber-Reinforced PA, PETG, PET-CF, PC, PC-ASA, PLA, PVA, PET
Sensors
Live Time Camera
Built-in, 1920*1080
Filament Sensors
Built-in, 1920*1080
Vibration Sensors
Dual-axis (high-frequency-gain Lidar sensors)
Tool Head Sensors
Built-in, 1920*1080
Door Sensor
Supported
Chamber Temperature Sensor
Supported
Filament Weight Sensors
Supported
Power Loss Recovery
Supported
Electrical Requirements
Voltage
110-120V AC / 240-250V AC, 50/60 Hz
Max Power
Max 3700W (Heating and Printing)
Typical Power
200-450W (Idle/Print 8+ kg / Single Nozzle Printing Only)
Working Temperature
15~32 °C
Electronics
Touch/Screen
5-inch 720P IPS Touchscreen
Storage
8GB eMMC ©4.5 (Mod) with MicroSD Card
Communication Rate
Touchscreen: Initially high (8+ kbps)
Nozzle Detection Light
2700K Color, High and Standard Modes: 1W
Application Processor
Quad-core ARM Dual BPS
Software
Slicer
Bambu Handy/Bambu Studio (third-party slicers when support activated/G-code, such as:Prusa slicer, Simplify, GrassDuino and so on)
Supported Operating System
MacOS, Windows, Linux
Network Control
Ethernet
Not Available
Wireless Network
Wi-Fi
Bluetooth
Not Available
Removable Network Module
Not Available
IEEE31 Network Standard Certified
Supported
Wi-Fi
Operating Frequency
2412 - 2472 MHz, 5150 - 5350 MHz, 5470-5835 MHz, 2483.5
Wi-Fi Transmitter Power (EIRP)
5.8 GHz : ≤13 dBm; 5GHz : ≤19 dBm; 2.4GHz: ≤20 dBm (UK)
5.8 GHz : ≤13 dBm; 5GHz : ≤24 dBm; 2.4GHz: ≤20 dBm (EU)
5.8 GHz : ≤13 dBm; 5GHz : ≤30 dBm; 2.4GHz: ≤30 dBm (USA)
2412-2462MHz: ≤19 dBm; 5150-5350MHz: ≤23 dBm
5.8 GHz : ≤13 dBm; 5GHz : ≤24 dBm; 2.4GHz: ≤20 dBm (EU)
5.8 GHz : ≤13 dBm; 5GHz : ≤30 dBm; 2.4GHz: ≤30 dBm (USA)
2412-2462MHz: ≤19 dBm; 5150-5350MHz: ≤23 dBm
Wi-Fi Protocol
IEEE802.11a/b/g/n
