Articulating Probe Head

For the Ultimate in Probing Flexibility Use either a Touch Trigger or Scanning Probe With a PH10 Plus





The PH10 PLUS comprises a family of motorized articulating probe heads designed to facilitate automatic tool reorientation, thereby increasing throughput and eliminating the need for multiple probe configurations.



These three distinct models can accommodate a variety of probes and accessories, significantly reducing the necessity for part reorientation or time-consuming tool changes from a change rack. With the ability to orient in up to 720 different repeatable positions, these probe heads enable direct access to most features.



The PH10T and PH10M are equipped with air deployment mechanisms for automatic deployment and retraction of the entire head when not in use. The PH10MQ, a variant of the PH10M, allows direct attachment of the head to the quill of a CMM.



All these variants are seamlessly controlled through the PHC10-3 PLUS head controller, ensuring seamless integration with OGP systems.



PH10T PLUS

Sensors: TP20 and TP200 touch probes

Systems: Optional on SmartScope Quest/Vantage 650 and 450 and 800 with 400 mm of Z travel

Software: ZONE3


PH10M PLUS

Sensors: SP25M Scanning Probe

Systems: Optional on SmartScope Quest/Vantage 650 and 450 and 800 with 400 mm of Z travel

Software: ZONE3


PH10MQ PLUS

Sensors: SP25M Scanning Probe, TeleStar® probe, and SmartProbe® video sensor

Systems: Standard on all floor model FlexPoint systems

Software: ZONE3
