Intamsys ULTEM 1010

ULTEM 1010 - Filament - Intamsys - Indicate Technologies
ULTEM 1010 - Filament - Intamsys - Indicate Technologies

ULTEM 1010

$108.00
Save {}Sold out

Ultem 1010 is a high-performance thermoplastic, PolyEtherImide (PEI), which offers excellent strength, thermal stability and the ability to withstand steam autoclaving.

The filament offers high-heat resistance, chemical resistance and tensile strength and is ideal for aerospace, automotive applications and others.

Color:
  • Natural
Diameter:
  • 1.75 mm
Weight:
  • 500 g
  • 1 kg
SKU: intamsys-ultem1010

Explore reasons for using Ultem 1010

Features

Applications

Properties

Compatibility

Features
- Very high chemical resistance
- Flame retardant UL94-V0 (for 1.5mm and 3mm)
- Can be used up to 200˚C / 394˚F HDT
- Compliant for food-grade applications - NSF 51
- Excellent for composite layup tooling
ultem-1010-filament-intamsys-indicate-technologies-215989
Applications
Ultem 1010 offers high-heat resistance, chemical resistance and tensilestrength and is ideal for aerospace and automotive applications.

Intamsys Ultem 1010 is a high-performance thermoplastic material that is ideal for creating functional parts and prototypes with excellent mechanical and thermal properties. Here are some common applications for Intamsys Ultem 1010:

Aerospace industry: Intamsys Ultem 1010 can be used to create aerospace components such as engine parts, brackets, and structural components. The high strength, stiffness, and temperature resistance of Ultem 1010 make it an ideal material for these demanding applications.

Automotive industry: Intamsys Ultem 1010 can be used to create automotive components such as under-hood components, electrical connectors, and fuel system components. The high strength, stiffness, and temperature resistance of Ultem 1010 make it an ideal material for these demanding applications.

Medical and dental applications: Intamsys Ultem 1010 is used to create medical and dental instruments and devices such as surgical tools, sterilization trays, and dental appliances. The high temperature resistance, biocompatibility, and sterilizability of Ultem 1010 make it an ideal material for these applications.

Industrial equipment: Intamsys Ultem 1010 is used to create industrial equipment components such as gears, bearings, and housings. The high strength, stiffness, and temperature resistance of Ultem 1010 make it an ideal material for these demanding applications.

Electrical and electronics industry: Intamsys Ultem 1010 can be used to create electrical and electronics components such as connectors, switches, and sockets. The high temperature resistance, dimensional stability, and chemical resistance of Ultem 1010 make it an ideal material for these applications.

Overall, Intamsys Ultem 1010 is a high-performance material that offers excellent mechanical, thermal, and chemical properties. Its unique combination of properties makes it suitable for use in demanding applications where high strength, stiffness, temperature resistance, chemical resistance, and biocompatibility are critical, including aerospace and automotive components, medical and dental instruments and devices, industrial equipment, and electrical and electronics components.
ultem-1010-filament-intamsys-indicate-technologies-776308
Properties
Density 1.27 g/cm³
Elongation at Break 3.3%
Extruder temperature 340–360 °C
Flexural Modulus 3,197 MPa
Flexural Strength 126 MPa
Glass Transition Temperature 215 °C
Heat deflection temperature (1.8 Mpa) 190 °C
Impact strength 4.9 kJ/m²
Print bed temperature 130–160 °C
Support material SP5080
Tensile Strength 90 MPa
Young’s Modulus 3,427 MPa
ultem-1010-filament-intamsys-indicate-technologies-776308
Compatibility
- Funmat Pro 610HT
- Match support material: SP5080
